E2000 fiber optic connectors and related products include both single mode and multimode types. There are single mode E2000 UPC connector, single mode E2000 APC connector and multimode E2000 UPC connectors, and there are adapters to use with them accordingly. E2000 products include simplex and duplex versions.
E2000 fiber optic connector and E2000 products are more and more used in the communication filed because its good performance. E2000 is a trademark of Diamond company and E2000 series include a wide range of different styles. Although E2000 is rather expensive than most of the other types fiber connectors, it indeed incorporate much innovative technology to improve the products performance, one of them is the E2000 featured Spring-loaded protective cap which provide increased safety protection.
E2000 fiber connector and related products comply with IEC 61 754-15 and TIA/EIA 604-16. We supply the E2000 connector, adapter and cable assemblies.
Features
● Low insertion loss and back reflection loss
● High precision alignment
● Compact design
● Plastic housing
● Telcordia, ANSI, TIA/EIA, NTT and JIS compliance
Application
● CATV
● Telecommunication networks
● Local Area Networks (LANs)
● Data processing networks
● Test equipment
● Premise installations
● Gigabit Ethernet
● Video
Product description
| Product name： | E2000 Adapter |
| Connector type： | E2000 |
| Meet the standards： | IEC/ROHS/SGS |
| Color： | Green |
| Fiber Mode： | SM |
| Sleeve： | Caremic/Phosphor Bronze |
| Green standards： | Yes |
Specification
|
Parameter |
Unit |
LC,SC,FC,ST,MTRJ,MPO,E2000 |
|||
|
SM |
MM | ||||
| PC | UPC | APC | PC | ||
| Insertion Loss(Typical) | dB | ≤0.2 | ≤0.2 | ≤0.2 | ≤0.2 |
| Return Loss | dB | ≥45 | ≥50 | ≥60 | ≥30 |
| Exchangeability | dB |
≤0.2 |
|||
| Repeatability | dB |
≤0.2 |
|||
| Durability | Time |
＞1000 |
|||
| Operating Temperature | ℃ |
-40 — +75 |
|||
| Storage Temperature | ℃ |
-40 — +85 |
|||
